DIP346 Outdoor Advertising LED Display P10mm With Novel Mask Setting
Ask Latest Price
Brand Name :HANJING
Model Number :P10mm DIP Outdoor Advertising LED Display
Certification :CE/ROHS/FCC/ETL/TUV
Place of Origin :ShenZhen，China
MOQ :1pc/1sqm
Price :Negotiation
Payment Terms :35% T/T as prepayment,65% T/T as balance at factory, Western Union, MoneyGram
Supply Ability :1000 sets per month
Delivery Time :8-25 working days after received your payment
Packaging Details :Plywood cartons or flight case packaging
Pixel Pitch :P10mm
LED Type :DIP346
Cabinet Size(WXH) :Can be customized
Cabinet Brightness :≤7500 nit
IP Grade :IP65
Cabinet weight :49kg/㎡
Refresh Rate :≥1920 Hz
Color Display :281 trillion
Cabinet Material :Iron box technology
Operating environment :oudoor：-20℃-60℃；
Driving Method :1/4 scan
more
Contact Now

Add to Cart
Find Similar Videos
Iron Cabinet Outdoor Led Video Display Board High Brightness Rgb P5 AC 200V/240V 00:21
Iron Cabinet Outdoor Led Video Display Board High Brightness Rgb P5 AC 200V/240V
P4mm Outdoor Advertising Led Display Full Color 6000cd Brightness 2 Years Warranty 00:21
P4mm Outdoor Advertising Led Display Full Color 6000cd Brightness 2 Years Warranty
Stage Full Color Video Wall Led Screen 8mm Pixel Pitch Outdoor 2 Years Warranty 00:22
Stage Full Color Video Wall Led Screen 8mm Pixel Pitch Outdoor 2 Years Warranty
RGB SMD3535 Outdoor Advertising LED Display Waterproof Ip65 High Brightness 00:12
RGB SMD3535 Outdoor Advertising LED Display Waterproof Ip65 High Brightness
1R1G1B P10mm LED Display Stadium Screen Outdoor Advertising Synchronous Control 00:15
1R1G1B P10mm LED Display Stadium Screen Outdoor Advertising Synchronous Control
Full Color P5 Outdoor Advertising LED Display 320*160mm Module Size 8 Scan Mode 00:16
Full Color P5 Outdoor Advertising LED Display 320*160mm Module Size 8 Scan Mode
High Brightness P10 Outdoor Advertising LED Display IP65 For Wall Mounting 00:22
High Brightness P10 Outdoor Advertising LED Display IP65 For Wall Mounting
outdoor rental led display screen P2.976mm,P3.91mm,500mm*500mm Die casting aluminum 03:40
outdoor rental led display screen P2.976mm,P3.91mm,500mm*500mm Die casting aluminum
6000cd High Brightness Transparent Glass LED Display P3.91mm IP65 Waterproof 00:13
6000cd High Brightness Transparent Glass LED Display P3.91mm IP65 Waterproof
View Product Description

P10mm outdoor full-color DIP LED display is mainly composed of red, green and blue DIP346 lamp beads. There are 10,000 pixels in a square meter, and the distance between each pixel is 10mm. The scanning mode is 4-scan, and the power consumption per square meter is about 300 watts per square meter. The novel mask setting makes the color mixing more even and the high-density pixel makes the picture quality clearer and the view Angle wider.
P10 outdoor full-color LED display applicable scope:
Outdoor P10LED full-color display screen is widely used in stadiums, squares, transportation, shopping malls, stations, hotels, guesthouses, airports, docks, schools and other outdoor occasions

Other Corresponding product specifications:
P3mm outdoor advertising Front Service LED Display
P4mm outdoor advertising Front Service LED Display
P5mm outdooradvertising Front Service LED Display
P6mm outdooradvertising Front Service LED Display
P8mm outdoor advertising Front Service LED Display
P10mm outdoor advertising Front Service LED Display
P16mm outdooradvertising Front Service DIP LED Display
P25mm outdooradvertising Front Service DIP LED Display
P31.25mm outdooradvertising Front Service DIP LED Display

Specifications:

ModuleTechnical Parameters
Pixel Pitch10mm
LED TypeDIP346
Module Size (mm)160mm × 160mm
Module Resolution16dots × 16dots
Module weight0.6kg
Brightness≤7500 nit
Refresh Rate≥1920 Hz
Driving Method1/4scan
Grey level16bits
Color Display281 trillion
IP GradeIP65
Power consumption (Max/Average)600/200 W/sq.m
LifeSpan100000 hour
Cabinet
Cabinet Size(WXH)Can be customized
Cabinet resolutionPixeles
Cabinet MaterialIron Box Technology
Cabinet weight(kg)49kg/㎡
Pixel density10000 Pixeles /m²
InstallationCrane Girder Hoisting And Fixed Installation
Control systemFull color asynchronous /synchronous
Data interconnectionWifi / USB / HDMI
SoftwarePC software or Android App or IOS App
Application environment
Input AC power voltage110V-240V
Working temperatureoudoor:-20℃~60℃
Working humidityhumidity:10%-90%RH
Signal type(with video processor)AV, S-Video, VGA, DVI, HDMI, SDI, DP
Control distanceHSYV: <100m; SMF: <10km
